CCKX18 series Busway is high strength fully enclosed reinforced insulation type, the shell of the product was rolled into ripple cover by galvanized steel and busbar conductor was fixed by ripple cover, so can withstand the thermal stress and electric power generated by high short-circuit current. CCKX18 reinforced insulation type busway with aluminum alloy shell and antisepsis busway have following features: generic and reliable structure, good showing, lightweight and so on. Antisepsis busway is widely used in petroleum, chemical and other harsh operating conditions ideal for transmission and distribution equipment. Standards:GB 7251.2-1997 ,JB/T 9662-1999, GB 7251.2-1997,GB 14048.1-2000 ，GB/T 4942.2-1993 Main features: Main Technical Data
Recommend Products Recommended by sellerprepaid electricity Meter energy power meter prepaid meter electricity meter$13.00 - $16.00 / Piece50 PiecesOEM 25A DC to AC Single Phase protection Relay Direct Current electric relays SSR Solid State Relays$3.00 - $4.00 / Set1 Setcontactor price AC contactor magnetic contactors$2.80 - $3.20 / Set5 SetsGSZ2 Range Single Pole Normally best price contactors 24v dc Contactor$3.20 - $4.00 / Set1 Set36V 18650 rear rack city bike Electric Bike lithium battery lithium ion batteries$142.00 - $180.00 / Set20 Setsbusbar copper busbar Busway machine$142.85 - $714.28 / Set1.0 Setsdistribution board electric control panel-cabinets electrical panel board$1,375.00 - $21,428.00 / Piece1.0 Piecesalcb rccb 400a alcb breaker box$4.80 - $342.00 / Set50.0 Setsmu Switchgear medium voltage switchgear high voltage switchgear$1,200.00 - $12,307.00 / Set1.0 SetsPortable 4 Inch 6 Digital LED Crossfit Interval Training Timer for GYM$19.60 - $83.74 / Set1.0 Sets40A 60A DC and AC Contactor New Type Control Device Contactor electric magnetic contactor$1.80 - $2.20 / Set1 SetVehicle charging station new Design Electric Vehicle Charge Pile Double Gun Station Charging Pile$17,000.00 - $19,000.00 / Set1 Set
Contact us if you need more details on Copper Busbar. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Busbar、Aluminum Busway. If these products fail to match your need, please contact us and we would like to provide relevant information.
OverviewCCKX18 series Busway is high strength fully enclosed reinforced insulation type, the shell of the product was rolled into ripple cover by galvanized steel and busbar conductor was fixed by ripple cover, so can withstand the thermal stress and electric power generated by high short-circuit current. CCKX18 reinforced insulation type busway with aluminum alloy shell and antisepsis busway have following features: generic and reliable structure, good showing, lightweight and so on. Antisepsis busway is widely used in petroleum, chemical and other harsh operating conditions ideal for transmission and distribution equipment. Standards:GB 7251.2-1997 ,JB/T 9662-1999, GB 7251.2-1997,GB 14048.1-2000 ，GB/T 4942.2-1993 Main features: Main Technical Data
Item | Parameters | ||||||
Power Frequency（Hz） | 50(60) | ||||||
Rated insulation voltage（V） | AC660 DC1000 | ||||||
Rated operating voltage（V） | AC220/380/660 DC800 | ||||||
Rated operating voltage of connecting unit（V） | AC220/380 | ||||||
Rated current（A） | 100、160 200、250 | 400、6300 800、1000 | 1250、1600 | 2000、2500、3150 4000、5000 | |||
Rated short-time withstand current（kA/s） | 12 | 30 | 50 | 80 | |||
Rated peak withstand current（kA） | 25 | 63 | 105 | 176 | |||
Wiring system | Three-phase three-wire、Three-phase four-wire Three-phase five-wire | ||||||
Degrees of protection | IP40 | ||||||
Contact us if you need more details on Copper Busbar. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Busbar、Aluminum Busway. If these products fail to match your need, please contact us and we would like to provide relevant information. Email to this supplier
