MCB 1P 2P 3P 4P C60 C65 IC65N Miniature Circuit Breaker MCB

Product Description

Product Overview GSB2 range mini-breakers are mainly used in the electrical circuit with AC frequency 50Hz or 60Hz, rated voltage up to 415V, rated current up to 63A and below to protect the circuit equipments or devices and the similar purposes, it also has isolation functions. The breakers can be matched with accessories such as the auxiliary contacts, the alarming contacts, shunt trip etc. so as to supply the auxiliary signals or realize its remote breaking functions. Product feature △ Conform to the following standers: IEC60898-1、GB10963.1. △ The products are all through the CCC certification, the EU CE safety certification and CB certification. Applied environment △ Environment temperature : -5℃~+40℃, the average hours of temperature exceeding +35℃ during 24 hours. △ Elevation: ≤2000m △ No exceeding 50% at the maximum ambient temperature of 40℃.with lower temperature, higher humidity would be permitted, for example ,with temperature 20℃, the humidity can exceed 90%.Take the special measure to the dews on the surface, which would appear due to temperature change △ Pollution protection: Grade 2 △ Products should be used in no significant impact and vibration place. △ Installing categories: Class Ⅲ △ Installing condition: mounted by TH35-7.5 standard rail track Product Parameters

Contact us if you need more details on circuit breaker. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Electrical Circuit Breakers、Miniature Circuit Breaker. If these products fail to match your need, please contact us and we would like to provide relevant information.

Product Categories : LV Electrical Components > Circuit Breaker
